Washington State Legislature Approves Ultrafine Particle Study for Jefferson and Clallam Counties

This is extremely good news to a start on finding out what kinds of pollution we are breathing and if the new biomass plants are actually doing something that needs cleaning up. That is, if they are built, which seems not a sure thing at this point in time, due to economics, not environmental concerns, unfortunately.

___________________________________________

The Olympic Clean Air Agency and the University of Washington propose to jointly study air quality in Jefferson and Clallam Counties. This project will evaluate possible air quality changes associated with new biomass co-generation facilities in Port Townsend and Port Angeles and changes in ultra-fine particle concentrations associated with both facilities. The project will support state of the art measurements of ultra-fine particles and will respond directly to concerns of the two communities around health effects and industrial development.

Background

Concerns regarding greenhouse gas emissions and climate change have encouraged the development of biomass fueled power stations, i.e. biomass cogeneration plants. The biomass fuel varies for each region and can include sugar-cane stalk, corn and rice straw, and palm and woody debris to name a few. This form of power generation is controversial within the “green” community. Proponents claim that burning biomass contributes a net zero addition to atmospheric carbon dioxide compared to fossil fuel combustion [Taylor, 2010]. The carbon released during biomass combustion will be re-used in plant material for the next cycle of energy generation, while fossil fuels represent carbon that has been stored for millennia. Since new co-generation plants are required to use Best Available Control Technology (BACT) to prevent degradation of air quality, supporters further argue that burning biomatter in the plant is cleaner than slash burning outdoors and actually helps improve air quality. Furthermore, industry has been burning biomass waste for years without converting it to usable power, and therefore claim a net gain in power produced vs. carbon released [Taylor, 2010]. The US Department of Energy recognizes biomass co-generation plants as a renewable energy source and has awarded grants to finance their design and operation. (http://www.srs.gov/general/news/releases/nr12_doe-biomass-startup.pdf)

Opponents of biomass fueled co-generation are primarily concerned about subsequent environmental damage and the cleanliness of the technology. They claim that burning biomass will endanger forest land by increasing logging operations and argue that slash should be left to decompose on the forest floor. The primary concern regarding biomass fueled power centers on the release of harmful toxins and fine particulate that can negatively impact the health of residents living near the co-generation plants. Specifically, activists are concerned about ultrafine particles –diameters less than 100 nm – that are not detected by standard air monitoring instruments [Keywooda et al., 1999] and to which recent research ascribes significant health impacts [Keywooda et al., 1999; Morawska et al., 2004].

Recently two new biomass cogeneration plants were approved for installation on the Olympic Peninsula, one at Nippon Paper Industries in Port Angeles and the other at Port Townsend Paper Company in Port Townsend. Both mills have been burning woody biomass as waste for several decades. Construction of these co-generation plants requires installation of emission control technology predicted to decrease the total PM2.5 emitted, despite increasing the mass of fuel burned by a factor of three. PM2.5 is the mass concentration of atmospheric particles with diameters less than 2.5 microns. Other gaseous emissions such as Volatile Organic Compounds and NOx will roughly increase by 35 and 18 tons per year respectively. Despite these pollution controls, and maybe because of them, there is concern that although PM2.5 will decrease, the number of ultrafine particles, which may be more hazardous to respiratory and cardio health, will increase. Research has shown that when PM2.5 decreases, co-emitted gases like SO2 and NOx have less surface area on which to condense and are thus more likely to homogeneously nucleate ultrafine particles downwind of the emission site [Weber et al., 1997]. Despite these concerns, there is very little data that show the impact of biomass cogeneration plants on local and regional air quality, including PM2.5 and ultrafine particulate.

Proposed Study

Port Angeles and Port Townsend are ideal locations to conduct a study focusing on the impacts of biomass fueled cogeneration facilities on air quality downwind of the cogeneration plants. Both towns have similar meteorology and environmental conditions. There are no other large industrial sources or major freeways to obscure ultrafine and fine particulate emissions from the biomass cogeneration plants, although emissions from residential burning in the winter constitute a large fraction of the observed PM2.5 in bothcities. Currently the Olympic Region Clean Air Agency (ORCAA) maintains a permanent air monitoring site for PM2.5 in both Port Angeles and Port Townsend. Data on background concentrations of PM2.5, SO2, NOx, CO, and ozone are also available from Cheeka Peak, an NCore site located west of Port Angeles on the northwestern tip of the peninsula and measuring some of the cleanest air in the country. In addition to the permanent monitors, ORCAA will also install four optical particle counters (OPC) that provide data on the number concentration of particles larger than 0.3 microns at three locations in Port Angeles and at one location in Sequim. The OPCs will operate between January 2013 and December 2013. These monitors will move to Port Townsend in 2014. In both Port Angeles and Port Townsend, one of the OPCs will be collocated with the permanent air monitor, a nephelometer. ORCAA also has two aethalometers that measure black carbon concentration and can be used to differentiate between wood combustion and diesel combustion. One aethalometer will be installed at the permanent monitoring location and the other will be installed along with an OPC at one of the other temporary sites. The existence of these monitoring locations creates an infrastructure that will facilitate a study of ultrafine particles and source types of air pollution in the region.

In addition to ambient monitoring that already occurs in Clallam and Jefferson Counties the Olympic Region Clean Air Agency, in collaboration with the University of Washington, proposes to conduct an additional study to examine the concentration, sources, and lifetimes of ultrafine particulate in Port Angeles and Port Townsend.

The scientific questions to be addressed are:

1) 2) 3)

4) 5) 6) 7)

Experiment

For this project we will establish two master research sites on the Olympic Peninsula. One will be located near residential areas of Port Townsend and the Port Townsend Paper Corp. The second site will be in Port Angeles near to the Nippon Paper Industries facility. At each site we will ideally conduct a series of pre/post-expansion intensive measurements that can complement the existing measurements using nephelometers, optical particle counters, and aethalometers. The Nippon co-generation plant, located in Port Angeles, expects to begin operating in September or October, 2013 and therefore baseline, winter measurements of ultrafine particles before operations commence may not be possible. To work around this issue, meteorology and plume dispersion modeling will allow data to be segregated to times when emissions from Nippon could affect measurements at the site and those times when they would not.

How will air quality respond to the change in emissions from the facility?

What is the distribution of PM2.5 in residential areas of both communities?

Is there evidence of an increase in ultrafine particulate matter from the expanded facilities?

What is the cause of the odors in the Port Townsend area and what can be done about these?

What are the source contributions to fine and ultrafine particulate in these two areas?

How does this change between winter and summer?

Which neighborhoods are most impacted by these facilities? Are the concentrations

reasonably modeled by a Gaussian plume distribution?

How do ultrafine particulate emissions from the facilities change in the winter relative to the summer?

Measurements of PM2.5, number concentration and size distribution of ultrafine particles (diameter < 100 nanometers), particle chemical speciation, and carbon monoxide will be made at both the Port Angeles and the Port Townsend sites. Continuous stack emission measurements at the facilities will complement the ambient measurements to determine their potential influence on the ambient air quality.

A proposed schedule for this work is as follows:
Summer 2013: 6-week experiment prior to facility modifications and expansion
Winter 2013: 6-week experiment prior to facility modifications and expansion (Port Townsend) Summer 2014: 6-week experiment after facility modifications and expansion
Winter 2014: 6-week experiment after facility modifications and expansion

Instruments and measurements that will be made in addition to those already made by ORCAA:

Instrument

What it measures

Scanning Mobility Particle Sizer (SMPS), TSI 3936

Ultrafine particle size distribution

Aerosol Mass Spectrometer (AMS)

Aerosol chemical composition

Chemical Ionization Mass Spectrometer (CIMS)

Aerosol chemical composition

TECO 48CTL

Carbon Monoxide

Dusttrak DRX 8543

Particulate matter

Shredded Scotch broom to help fuel Harmac pulp mill – Times Colonist

If we are going to get forced by our legislators to have biomass plants, (which is now becoming doubtful given the latest feedback from the new PT Mill manager who said in his first interview that the economics of it was shifting and there was no guarantee that they would build the plant),  here’s a use for the new biomass plants that we can all get behind.

The City of Nanaimo has found a use for Scotch broom. The noxious weed will be shredded and burned as hog fuel to power the Harmac pulp mill near Nanaimo. This year for the first time, the city helped members of the public control the noxious weed by putting collection bins at three locations in May. Enough broom was collected to more than fill a five-ton truck. It was shredded Thursday at a ceremonial “burning of the broom” event at the fire-training yard on Labieux Road. Darrell Belaart reports.

http://www.timescolonist.com/news/shredded-scotch-broom-to-help-fuel-harmac-pulp-mill-1.317110

Biomass Town Hall Meeting in PA- March 11


Two views on future of biomass

The battle over biomass promise vs. reality continued last week, moving to Olympia … in my opinion, it seems better for the environment to be burning natural gas than wood waste..And then there’s that pesky bill that would put the decision to approve biomass sites into the hands of an unelected state commission. A recipe for manipulation by the biomass industry, it seems to me.

2/3 Olympian
Two views on future of biomass
JOHN DODGE; Staff writer

The Thurston County moratorium on new biomass-energy projects drew both criticism and praise Wednesday, from the county courthouse to the state Capitol.

Officials from The Evergreen State College met with the county commissioners in the morning, calling for an exemption from the moratorium so the college can use wood waste rather than natural gas to heat the campus.

More at
http://www.theolympian.com/2011/02/03/1529846/2-views-on-future-of-biomass.html

Appeal filed against Nippon biomass plan – PDN

—–
1/20 Peninsula Daily News
State appeal filed against Nippon biomass plan; foes await summer hearing on Port Townsend mill biomass upgrade
By Tom Callis
Peninsula Daily News

The second round of appeals for a biomass energy project in Port Angeles has begun, while opponents await a separate state hearing on an appeal filed in November against a biomass project proposed in Port Townsend.

Six of the seven environmental groups that lost an appeal of the shoreline substantial development permit that the city of Port Angeles gave Nippon Paper Industries USA are taking their case to the state Shoreline Hearings Board.

More at
http://www.peninsuladailynews.com/article/20110120/news/301209982/state-appeal-filed-against-nippon-biomass-plan-foes-await-summer

—-

Biomass clear of EPA rules for 3 years

Ed: I am looking into who in our delegation was petitioning the EPA to do this, and apparently Representative Van De Wege and Lynn Kessler were part of the group that asked for this. There appears to be a backstory here, and I’m contacting some individuals who gave them the technical reasons to ask for the deferal. More to follow as the week progresses.

————————————————-
1/17 Peninsula Daily News – Biomass clear of EPA rules for now as agency defers action for 3 years for analysis
By Tom Callis
Peninsula Daily News

Wood-burning facilities will not be regulated under the Environmental Protection Agency’s new greenhouse gas regulations that went into effect earlier this month, the federal agency announced last week.

EPA said it will defer further action on the matter for three years while it analyzes whether the burning of wood waste to produce electricity, among other uses, can really be considered “green.”

The move came after proponents of biomass energy, including Washington state officials and some members of Congress, protested the inclusion of biomass projects under the new regulations.

More at
http://www.peninsuladailynews.com/article/20110117/news/301179997/biomass-clear-of-epa-rules-for-now-as-agency-defers-action-for-3
